Y190 – Long Range Fixed Wing Drone

Y190 – Long Range Fixed Wing Drone

The Y190 is a high-perfonnance fixed wing UAV with a payload capacity of 190 kilograms. It can be quickly assembled and disassembled, and supports fully autonomous flight, short takeoff, and landing. The drone has two abdominal mounting points, which can...

Category: Drone, Fixed-Wing

Specification:

  • Maximum Load capacity 190kg
  • Maximum takeoff weight 470kg
  • Load endurance 5h@190kg/27h@60kg
  • Cruising speed 200km/h
  • Maximum range 3500km
  • Flight altitude 5000m

The Y190 is a high-perfonnance fixed wing UAV with a payload capacity of 190 kilograms. It can be quickly assembled and disassembled, and supports fully autonomous flight, short takeoff, and landing. The drone has two abdominal mounting points, which can carry different types of payloads simultaneously.

Specification:

Maximum Load capacity Maximum takeoff weight Load endurance Cruising speed Maximum range Flight altitude Overall dimensions Takeoff distance Maximum takeoff/landlng altitude Effective load power supply Fuel type
190kg 470kg 5h@190kg/27h@60kg 200km/h 3500km 5000m 5500*8400*1700mm 300m 2000m 2kW 95#gasoline
